10' 176T HBM 176/3200M E22 Hydraulic Press Brake NEW

High-Speed Fiber Laser Cutter — USA Warranty
$38,900.00 USD
$38,900.00 USD
Sale Sold out
Shipping calculated at checkout.

🇺🇸 UmproTech 10' 176T — HBM 176/3200M E22 Hydraulic Press Brake

Heavy-duty 10-ft precision press brake • E22 CNC control • U.S. setup, training & support

Key Specifications

Press Force
176 tons (≈1,600 kN)
Bending Length
126" (3,200 mm)
Motor Power
15 HP (11 kW)
Working Speed (Bending)
~0.31 in/s (8 mm/s)
Machine Weight
≈19,840 lbs (9,000 kg)
Controller
E22 CNC — step/angle programs, parts counter, memory programs
In-Stock USA (Chicago) 2-Year Parts & Electronics Warranty Setup & Operator Training Included Financing & Leasing Available
Financing:
  • Request a Quote
  • Leasing Options Available

See more hydraulic press brakes or explore our fiber laser cutters.

View full details

10' x 175 Ton E22 HBM 176/3200

PREMIUM PRECISION. BUILT FOR AMERICAN MANUFACTURING.
CNC AUTOMATION UmproTech HBM 175/3200 — 10-foot 175-ton CNC hydraulic press brake with E22 2-axis control
2-Year Premium Warranty
ISO 9001 Certified
American-Owned
Nationwide Installation

Included Options

E22 CNC Control (2-Axis)
SICK Model 4000 Light Curtain

Optional Upgrades

Fiessler AKAS II Laser Guarding
Pilz PSENvip LED Safety Guarding
Third Axis (Backgauge Height)
Mechanical Auto-Crown (CNC-controlled)
High-Speed Servo Backgauge
Training at UmproTech or on-site

175 Ton × 10′ Hydraulic CNC Press Brake

Model HBM 175/3200 • E22 Controller

Upgrade your fabrication line with the UmproTech HBM 175/3200. This heavy-duty, 10-foot press brake pairs 175-ton forming capacity with E22 CNC automation to deliver faster setups, consistent angles, and reliable throughput for complex parts.

Standard Features

  • Ram Deflection Adjustment — precise, consistent bends across full length
  • Mechanical Ram Depth + Torsion Bar — parallelism & repeatability
  • Forged Heavy-Duty Cylinder & Steel Frame — built for continuous industrial duty
  • Three-Speed Ram — rapid approach • precise bend • fast return
  • Programmable Bottom Dwell — for specialty forming
  • Modes — inching • single • continuous
  • American Tang Tooling — 1/2″ × 5/8″, deep-box capable
  • Bed Tooling Slots & Capture Clamps — flexible setups

Key Specifications

Press Force
175 short tons
Bending Length
125.9 in (≈3200 mm)
Between Housings
106.3 in
Throat Depth
12.5 in
Ram Stroke Adjustment
2.75 in
Ram Travel
5.9 in
Open Height
16.3 in
Rapid Approach / Return
2.4 / 2.0 in/s
Working Speed
Tool-dependent
Backgauge Travel
24.0 in
Hydraulic Oil Capacity
~79 gal
Main Motor Power
15 HP
Net Weight
~22,000 lb
Machine (L × W × H)
148 × 64 × 101 in

Why Choose UmproTech HBM 175/3200?

U.S.-ready: safety & electrical compliance • E22 automation: faster setups & repeatability • Industrial build: forged hydraulics, rigid frame • Operator safety: SICK light curtain included • U.S. support: inventory in IL, nationwide service/training.

Request Custom Quote Book a Live Demo – Chicago Financing from $5xx/mo*
Speak to an Engineer: +1 (800) UMPROTECH
