5'x10' Fiber Laser for Metal Sheet Cutting Machine 1530B Open Type
UmproTech 1530B Fiber Laser Cutting System
Closed Commercial Proposal. High-performance fiber laser cutter engineered for precision, speed, and durability. Designed for U.S. manufacturing with world-class components and full technical support.
⚡ MAXPHOTONICS Fiber Laser
1500W / 2000W / 3000W / 6000W. Up to 100,000 hours lifespan, 2-year warranty.
🔍 UMPROTECH CH3000 Head
Autofocus, precise and low-maintenance.
🦾 Premium Motion System
LAPPINGS linear guides (Taiwan), GARRETSON helical rack (Germany), SHIMPO reducer (Japan), Leadshine servo motors (Taiwan).
🌡️ Industrial Chiller
HUA KU closed-loop water cooling for maximum stability.
🪨 All-Steel Welded Frame
Stress-relieved, heat-treated for rigidity and vibration resistance.
✈️ Aviation Aluminum Gantry
Lightweight, rigid, reduces motor wear and increases lifespan.
🕹️ User-Friendly CNC
RU CUT V2 controller, Windows-based console, ergonomic wireless remote.
🧰 Centralized Lubrication
Automated system for consistent, low-maintenance operation.
💨 Aspiration System
Integrated dust and fume extraction included.
🪚 Saw-Tooth Worktable
Replaceable steel slats for durability, low consumable cost.
🆔 Model
1530B
📏 Working Area
1530 × 3050 mm (60″ × 120″)
⚡ Laser Power
1500W / 2000W / 3000W / 6000W
🔬 Laser Head
UMPROTECH CH3000 (autofocus)
🌈 Wavelength
1070 nm
⏳ Laser Lifespan
up to 100,000 hours
🛡️ Warranty
2 years (laser/source)
❄️ Cooling
Industrial Chiller (HUA KU, China)
🛤️ Guide Rails
LAPPINGS 25mm, Taiwan
⚙️ Transmission X/Y
Dual-driven helical rack & pinion, GARRETSON (Germany)
⚙️ Transmission Z
TBI Ball Screw (Taiwan)
📏 Height Sensor
Automatic
⚙️ Reducer
SHIMPO - NIDEC (Japan)
⚡ Servo Motors
Leadshine 0.75kW (X/Y), 0.4kW (Z), Taiwan
🔌 Electrical Components
SCHNEIDER (France)
🎯 Positioning Accuracy
±0.03 mm
🔁 Repeatability
±0.02 mm
🚀 Acceleration
up to 1G
🔪 Max Cutting Thickness
up to 10 mm (carbon steel)
🏎️ Max Cutting Speed
up to 30 m/min (1,181 in/min)
🛣️ Max Traverse Speed
up to 100 m/min (3,937 in/min)
📏 Min. Cut Width
0.12 mm
🔌 Voltage / Frequency
380V, 50Hz
📄 File Formats Supported
CAD, CorelDRAW, PLT, AI, DXF
📦 Machine Dimensions
4400 × 2300 × 1600 mm (173″ × 91″ × 63″)
⚖️ Weight
2,300 kg (5,070 lbs)
Why Choose UmproTech?
🏭
U.S. Based Support
Local warehouse, technical support, and installation services across North America.
🛡️
Comprehensive Warranty
2-year warranty coverage with lifetime technical service support.
🎓
Operator Training
Free comprehensive operator training included with every system purchase.
