UmproTech HBF 70/2500 – 70 Ton 6-Axis CNC Press Brake, 2500 mm
The UmproTech HBF 70/2500 is a 70 ton, 2500 mm 6-axis CNC press brake engineered for US job shops, fabrication facilities and OEM plants that live on high-precision, high-mix sheet metal work. It combines a DELEM DA-66T graphical control, full 6-axis backgauge and a rigid welded frame to deliver fast changeovers, complex geometries and repeatable accuracy in demanding production environments.
Capacity: 70 ton · Bending length: 2500 mm · Axes: 6 (Y1/Y2, X, R1/R2, Z) · Controller: DELEM DA-66T
Overview & positioning for US shops
The UmproTech HBF 70/2500 represents the next generation of CNC press brake technology for North American fabrication. With 70 tons of forming force and a 2500 mm working length, it targets shops that need high precision, short setup times and complex part capability more than extreme tonnage.
It is ideal for:
- Job shops running high-mix, low-to-medium volume work with frequent changeovers.
- OEMs producing repeat parts that demand tight angles, consistent flange lengths and clean cosmetics.
- Automation cells where the brake must interface cleanly with robots, conveyors or part positioners.
Typical users include aerospace component manufacturers, heavy equipment builders, architectural metalwork fabricators, defense contractors and contract manufacturers. The DELEM DA-66T graphical CNC provides intuitive, visual programming while the heavy, stress-relieved frame and precision ways maintain accuracy in multi-shift, continuous production.
Why US buyers choose the HBF 70/2500
- DA-66T graphical control: 3D bending simulation, bend sequence support and collision checking help reduce trial parts and setup time.
- True 6-axis control (Y1, Y2, X, R1, R2, Z): independent ram, backgauge and finger movement for complex geometry, asymmetric parts and staged setups.
- 70 ton hydraulic system: sized to run continuous production duty cycles on common light-to-medium gauge materials.
- 2500 mm working length: covers a wide range of panels, doors, frames and profiles with minimal repositioning.
- Heavy welded, stress-relieved frame: minimizes deflection for long-term geometric stability and repeatable bending results.
- Automation-ready: standard interfaces for robotic loading/unloading and cell integration.
- Precision-ground hardened ways: guided ram motion with automatic centralized lubrication for low wear and easy upkeep.
- High-resolution linear scales: real-time feedback for closed-loop positioning and angle consistency.
- Graphical angle measurement: eliminates manual protractor checks and reduces dependency on “tribal knowledge.”
- Quick-change tooling: compatible with common American and European style punches and dies.
- Integrated safety package: light curtains, e-stops, mechanical guards and dual-hand controls as standard.
- Energy-efficient hydraulics: variable displacement pump reduces power draw and heat generation.
- US-friendly electrical spec: 480 V / 3-phase / 60 Hz for straightforward plant integration.
- Local support & training: US-based technical assistance, operator training and documentation.
High-level technical specification (summary)
| Machine type | 6-axis CNC synchronous hydraulic press brake |
|---|---|
| Bending capacity | 70 metric tons (approx. 77 US tons) |
| Bending length | 2500 mm nominal working length |
| Control system | DELEM DA-66T graphical CNC (6-axis control) |
| Frame construction | Heavy steel plate welded structure, stress-relieved |
| Drive system | Hydraulic synchronous system with servo-proportional valves |
| Positioning accuracy | ±0.001" via linear encoder feedback (application-dependent) |
| Electrical service | 480 V / 3-phase / 60 Hz (standard US industrial power) |
| Typical materials | Mild steel, stainless, aluminum, copper and other non-ferrous alloys |
| Duty cycle | Multi-shift, continuous production (24/7 capable with proper maintenance) |
| Standard safety | Dual-hand controls, light curtains, mechanical guards, e-stops |
Geometry & working envelope
Bending length:
2500 mm nominal capacity with clearance for common tooling setups, staged tools and standard sheet widths used in enclosure, panel and bracket work.
Axis configuration:
Full 6-axis control (Y1, Y2, X, R1, R2, Z) providing independent ram control, backgauge positioning and flexible finger positions for asymmetric and multi-station parts.
Daylight opening:
Generous daylight designed to support deep box forming, return flanges and multi-bend components commonly used in structural and enclosure fabrication. Final daylight is confirmed to match your tooling strategy.
Throat depth:
Sized for standard American material formats with clearance to reach interior bends, channels and offsets while maintaining safe operator access.
Backgauge range:
Extended X-axis travel supports both very small precision parts and larger panel bends, so the same machine can run brackets, channels and medium panels without compromise.
Physical size, footprint & weight
Machine footprint:
Compact overall length and depth to fit into U-shaped work cells and tight shop layouts, while preserving frame stiffness and ergonomic operator access.
Overall weight:
Heavy-mass construction typical of this tonnage class, providing vibration damping, thermal stability and solid forming performance over years of use.
Height clearance:
Designed to fit standard US industrial building heights with allowance for overhead cranes, jib cranes or lift assist systems above the machine.
Floor loading:
Requires an industrial-grade concrete slab typical for capital equipment; foundation recommendations and anchor patterns are supplied for your plant engineer.
Structure & mechanical design
Frame construction:
Heavy steel plate welded frame with computer-optimized ribbing, stress-relieved to remove internal stresses and maintain geometry over the life of the machine.
Ram guidance system:
Precision-ground hardened steel ways with large bearing surfaces to resist deflection and maintain parallelism under load, even at the edges of the working envelope.
Deflection compensation:
Hydraulic crowning with CNC-controlled adjustment keeps bend angles consistent across the entire 2500 mm length, reducing rework and manual shimming of dies.
Ram / slide construction:
Integral forged steel ram with high surface hardness and precision machining for accurate tool seating, long-term flatness and stable clamping of punches.
Drive system, hydraulics & motors
Hydraulic system:
Variable displacement axial piston pump with servo-proportional valve control delivers precise flow and pressure for smooth approach, bending and return phases while minimizing energy usage and heat.
Ram synchronization:
Electro-hydraulic servo control with high-response valves and linear encoder feedback keeps Y1/Y2 synchronized and maintains ram parallelism under varying loads and positions.
Main motors:
Industrial-grade three-phase induction motors sized for continuous duty and built for US power supplies, providing reliable drive power over multi-shift operation.
Backgauge drive:
AC servo motor with precision ball screw transmission provides fast, accurate X-axis positioning for high-volume work and tight tolerance flange lengths.
Controls, electronics & automation
CNC system:
DELEM DA-66T with 15" color TFT display, graphical programming, 2D/3D part visualization, bend sequence assistance and collision detection to help prevent crashes and reduce trial setups.
Programming interface:
Touchscreen graphical input, DXF import capability, offline programming support and built-in bend sequence optimization for fast job creation and changeover.
Position feedback:
High-resolution linear scales on each side of the frame, with micron-level resolution, feeding real-time position data into the CNC for closed-loop control of the ram axes.
Automation interfaces:
Standard Ethernet, RS-232 and fieldbus options for integration with robots, conveyors, pallet systems and factory MES/ERP networks as required by your plant IT standards.
Angle measurement:
Graphical angle measurement and correction functions reduce manual checking and help less-experienced operators achieve consistent results quickly.
Cooling, lubrication & utilities
Hydraulic cooling:
Air-oil heat exchanger with thermostatic control to keep hydraulic oil within optimal temperature range during extended production runs and multi-shift operation.
Way lubrication:
Automatic centralized lubrication with programmable intervals and low-level alarms, simplifying maintenance and protecting sliding surfaces from premature wear.
Electrical requirements:
480 V / 3-phase / 60 Hz supply with proper grounding, compatible with standard US industrial power distribution practices and panels.
Air supply:
Clean, dry compressed air for auxiliary functions and safety systems, within ranges typical of US industrial shop air installations.
Safety, guarding & environmental management
Operator safety:
Dual-hand anti-tie-down controls, Type 4 light curtains, mechanical guards and emergency stop circuits designed to align with ANSI B11.3 press brake safety guidelines (final configuration per order).
Noise control:
Hydraulic system layout and vibration-damping frame design help keep noise levels within typical industrial requirements for fabrication equipment.
Electrical safety:
UL-recognized components, segregated high/low-voltage areas, ground fault protection, main disconnect and clearly labeled circuits in the electrical cabinet.
Maintenance safety:
Mechanical ram supports, lockout/tagout provisions and clearly documented procedures for safe service and inspection tasks.
Installation, foundations & facility requirements
Foundation requirements:
Reinforced concrete slab or foundation with sufficient mass and anchor pattern to stabilize the machine and dampen vibration; detailed foundation drawings are supplied.
Floor space planning:
Recommended clearances for raw material staging, part manipulation, forklift or crane access and safe operator movement around the machine.
Utility connections:
Standard industrial connections for power, compressed air and local lighting around the operator station, aligned with typical US plant practices.
Rigging & placement:
Designed for conventional rigging with clearly marked lift points and suggested handling methods to simplify delivery, offloading and final placement.
Subsystems & accessories
Tooling interface:
Standard American-style clamping, with availability of European-style adapters; supports a broad range of industry standard punches and dies for maximum flexibility.
Hydraulic filtration:
High-efficiency filters with condition indicators and recommended replacement intervals to protect valves and pumps and extend hydraulic component life.
Electrical cabinet:
Industrial-rated enclosure with thermal management, clear wire labeling and service-friendly layout for faster troubleshooting and maintenance.
Standard configuration – what you get
- DELEM DA-66T CNC control with 15" color display.
- 6-axis control (Y1, Y2, X, R1, R2, Z) with servo-driven backgauge.
- Hydraulic crowning compensation system.
- High-resolution linear scales on both sides of the frame.
- Graphical angle measurement and correction functions.
- Automatic centralized lubrication system.
- Dual-hand anti-tie-down operator station.
- Type 4 safety light curtains and mechanical interlock guards.
- Emergency stop circuits and main power disconnect.
- Hydraulic oil cooling system and initial hydraulic fluid fill.
- Standard American-style tool clamping system.
- Basic punch and die set for common air-bending work.
- Complete electrical cabinet with labeled circuits.
- Machine leveling pads and anchors.
- RS-232 and Ethernet communication interfaces.
- Offline programming license or connectivity (per configuration).
- Operator and maintenance manuals (digital and print).
- One-year standard warranty coverage (extended options available).
Capabilities & typical applications
The HBF 70/2500 is designed to process a wide range of materials, including mild steel (up to appropriate thickness within its 70 ton window), stainless steel, aluminum alloys, copper and brass. Exact thickness and length combinations are confirmed via tonnage charts and part review.
Typical applications include:
- Structural components and brackets for heavy equipment and machinery.
- Enclosures and cabinets for electrical and control systems.
- Architectural metalwork such as panels, trims and façade elements.
- Aerospace brackets, supports and structural subcomponents.
- Defense-related parts and armored components within the machine’s capacity window.
It is equally comfortable running prototypes and small batches as it is running medium-volume production in the hundreds of pieces. Graphical programming and quick-change tooling enable changeovers in minutes instead of hours, helping job shops boost overall equipment effectiveness and responsiveness.
Industries served include metal service centers, contract manufacturers for OEMs, custom fabrication shops and in-house manufacturing departments across energy, construction, industrial machinery, aerospace, defense and more.
Implementation, integration, ROI & support
Implementation follows standard best practices: foundation preparation, utility connection and precise leveling to ensure the brake performs to specification. With proper site prep and rigging, typical on-site installation and commissioning can be completed within several days.
Operator training covers DELEM control programming, practical bending techniques, safety procedures and basic maintenance routines. Training can be delivered on-site at your facility or at regional centers, with digital and printed documentation provided.
Many US shops see payback in roughly 18–36 months based on increased throughput, shorter setup times, reduced scrap and more consistent part quality. Built-in automation readiness allows you to add robots, conveyors or other automation later as volumes grow.
Technical support includes phone and online assistance, regional field service and stocked spare parts to minimize downtime. Preventive maintenance programs with scheduled inspections help maintain uptime and catch issues before they impact production.
Extended technical FAQ
What are the basic facility requirements?
You’ll need a reinforced concrete foundation, 480 V / 3-phase / 60 Hz electrical service, clean compressed air and adequate overhead clearance for material handling and crane access. Detailed foundation and utility drawings are supplied with the project documents.
What operator skill level is required?
Basic CNC experience is helpful, but the DELEM DA-66T interface is designed to shorten the learning curve. With training, most operators reach productive levels within days, not weeks.
How does the 6-axis system improve accuracy?
Independent Y1/Y2 control, servo-driven X/R/Z axes and CNC crowning allow the machine to maintain parallelism, angle and flange length even on asymmetric or multi-step parts, while automatically compensating for load-induced deflection.
What maintenance is required?
Daily visual checks, weekly lubrication system checks, periodic hydraulic and filter inspection, and an annual full service by qualified technicians. The operator manual includes detailed schedules and checklists.
Can this machine be integrated with robots?
Yes. The HBF 70/2500 includes standard interfaces for robotic loading/unloading, and has been integrated with major robot brands commonly used in US manufacturing cells.
What are typical setup times?
For most jobs, changeovers fall in the 5–15 minute range depending on tooling and complexity. Graphical programming, job memory and quick-change tooling help keep setups short and predictable.
What safety standards does it meet?
The machine is designed around ANSI B11.3 concepts for press brakes and uses CE-marked safety components. Specific compliance documentation is available as part of the project package.
What uptime can we expect?
When operated within spec and maintained properly, the machine is designed for 95%+ uptime in continuous production, supported by regional service and parts availability.
How does it handle different materials and thicknesses?
The DA-66T control includes material libraries with tunable parameters for different grades and thicknesses. The hydraulic system provides fine pressure control, and operators can add or adjust material profiles to match real-world behavior and maintain consistent bend results.
