UmproTech HBF 110/2500 – 110 Ton 6-Axis CNC Press Brake, 2500 mm
The UmproTech HBF 110/2500 is a heavy-duty 6-axis CNC press brake engineered for demanding US fabrication, OEM, and contract manufacturing environments. With 110 tons of forming force, a 2500 mm (98.4") bending length, and a DELEM DA-66T graphical controller, it is purpose-built for high-mix, tight-tolerance work where uptime, repeatability, and fast changeovers directly impact profitability.
Capacity: 110 ton · Bending length: 2500 mm (98.4") · Axes: 6 (Y1, Y2, X, R, Z1, Z2) · Controller: DELEM DA-66T CNC · Hydraulics: Bosch-Rexroth
Overview & positioning
The UmproTech HBF 110/2500 is positioned for US job shops, fabrication plants, and OEM facilities that need more forming power and rigidity than light-duty brakes, but still require the flexibility and footprint of a 2500 mm machine. It bridges the gap between compact 50–70 ton models and large, long-bed brakes, making it an ideal “workhorse” for medium-format, higher-thickness parts.
With its 110 ton capacity, 6-axis backgauge and DA-66T control, the HBF 110/2500 is especially suited for:
- Shops bending thicker mild steel and stainless parts in medium lengths with tight angle tolerances.
- Mixed production environments that switch frequently between brackets, frames, panels, and welded assemblies.
- Cells integrating fiber lasers, turret punches, and welding stations in a lean, flow-oriented layout.
- OEMs that must maintain repeatable quality across multiple shifts and operators.
The combination of Bosch-Rexroth hydraulics, a rigid welded frame, and closed-loop position feedback gives the machine the stability required for demanding industrial environments, while the DELEM DA-66T keeps programming and operation approachable for production teams.
Key advantages for US buyers
- 110 ton forming capacity handles thicker gauge mild steel and stainless for structural brackets, frames, and heavier enclosures.
- 2500 mm (98.4") bending length supports standard sheet widths, medium-length parts, and multi-station staged tooling setups.
- Full 6-axis CNC backgauge (Y1, Y2, X, R, Z1, Z2) enables complex geometries, asymmetric bending, and flexible finger positioning.
- DELEM DA-66T touchscreen with graphical programming, 2D/3D simulation, and bend sequence optimization reduces setup time and scrap.
- Bosch-Rexroth hydraulic components deliver stable pressure, smooth ram motion, and long service life in harsh production environments.
- Servo-driven backgauge ensures fast, precise X/R/Z repositioning for high-mix/low-volume as well as repeat runs.
- Heavy welded, stress-relieved frame minimizes deflection for consistent angles across the full 2500 mm length.
- Automation-ready design with Ethernet, fieldbus, and I/O interfaces for robotic tending and conveyor integration.
- Standard 480 V / 3-phase / 60 Hz electrical service fits US industrial power without special transformers.
- Integrated safety package (light curtains, guards, dual-hand control, e-stops) aligned with US press brake safety practices.
High-level technical specification
| Machine type | 6-axis CNC synchronous hydraulic press brake |
| Bending capacity | 110 metric tons (approx. 121 US tons) |
| Bending length | 2500 mm (98.4") nominal working length |
| Control system | DELEM DA-66T graphical CNC with 6-axis control |
| Frame construction | Heavy steel plate welded structure, stress-relieved |
| Drive system | Hydraulic synchronous system with servo proportional valves |
| Axes | Y1, Y2, X, R, Z1, Z2 (ram + backgauge + finger positioning) |
| Positioning accuracy | Up to ±0.001" class via linear encoder feedback (application dependent) |
| Hydraulic components | Bosch-Rexroth valves, pumps, and manifolds |
| Electrical service | 480 V / 3-phase / 60 Hz (other voltages configurable) |
| Typical materials | Mild steel, stainless steel, aluminum, copper alloys and other sheet/plate metals |
| Duty cycle | Designed for multi-shift, continuous production with proper maintenance |
| Standard safety | Dual-hand controls, light curtains, mechanical guards, emergency stop circuits |
Geometry & working envelope
Bending length:
2500 mm nominal working length, sized for common sheet widths and medium-format parts, with additional clearance to support multi-station tooling setups and gauge positions.
Axis configuration:
Full 6-axis control: independent Y1/Y2 ram cylinders, X depth, R vertical gauge height, and Z1/Z2 programmable finger spacing for flexible support of asymmetric and complex components.
Daylight opening:
Generous daylight (defined in the detailed spec sheet) suitable for tall tools, return flanges and stacked tools used in staged bending of structural and enclosure parts.
Throat depth:
Engineered to reach deeper flange locations and interior bends while maintaining structural rigidity and operator access along the side frames.
Backgauge range:
Extended X and R travel to support both small precision parts and larger panels. Z1/Z2 axes allow independent finger positioning along the bed for staged setups and irregular part shapes.
Physical size, footprint & weight
Machine footprint:
Compact front-to-back depth and 2500 mm working width allow the HBF 110/2500 to fit in flexible cells, line layouts, or stand-alone forming areas without consuming excessive floor space.
Overall weight:
Heavy-mass construction typical for this tonnage class, providing vibration damping, structural rigidity and long-term dimensional stability under full-load conditions.
Height clearance:
Suitable for standard US industrial building heights, with adequate overhead clearance for crane or hoist lifting of plates, frames, and welded assemblies into position.
Floor loading:
Requires an industrial-grade concrete slab or foundation; floor loading and anchor layout are supplied for facility planning and structural review.
Structure & mechanical design
Frame construction:
Heavy steel plate welded frame with FEA-optimized ribbing, stress-relieved after welding to remove internal stresses and ensure long-term parallelism and alignment under 110 ton loading.
Ram guidance:
Precision-ground hardened ways and large bearing surfaces maintain ram guidance and reduce wear, even under off-center or staged bending conditions common in high-mix production.
Crowning / deflection compensation:
CNC-controlled hydraulic crowning system compensates for natural frame and bed deflection, maintaining consistent bend angles end-to-end across the full 2500 mm length.
Ram / slide construction:
Robust integral ram machined to tight tolerances provides a stable, accurate mounting surface for punch clamps and ensures reliable tool seating over the life of the machine.
Drive system, hydraulics & motors
Hydraulic system:
Variable-displacement axial piston pump with Bosch-Rexroth servo-proportional valve control provides smooth, precise ram motion and energy-efficient operation across the full speed and load range.
Ram synchronization:
Electro-hydraulic synchronization of Y1/Y2 cylinders using high-response valves and linear scales ensures parallel ram position and stable angle control from part to part.
Main motors:
Industrial three-phase induction motors sized for continuous-duty operation on 480 V / 60 Hz power, designed to handle long production shifts with minimal thermal stress.
Backgauge drive:
Servo motor-driven X and R axes with ball screw and linear guide transmission for fast, accurate repositioning; Z1/Z2 axes provide independent lateral finger movement for staged jobs.
Controls, electronics & automation
CNC system:
DELEM DA-66T with 15" color TFT touchscreen, providing graphical part programming, 2D/3D visualization, automatic bend sequence creation and collision checks to reduce trial-and-error.
Programming interface:
Intuitive graphical input, DXF import capability (where configured), offline programming and job library functions help standardize programs across shifts and plants.
Position feedback:
High-resolution linear scales mounted directly to the frame deliver real-time ram position feedback, enabling closed-loop control of depth and angle.
Automation interfaces:
Ethernet, RS-232, and fieldbus options support integration with robots, conveyors, and plant networks for Industry 4.0 connectivity, data collection, and remote diagnostics.
Angle management:
Built-in bend libraries and angle correction functions support consistent bending across different materials and gauges once programs are dialed in.
Cooling, lubrication & utilities
Hydraulic cooling:
Air-oil heat exchanger with thermostatic control maintains stable oil temperature during extended production, helping protect seals, pumps and valves from overheating.
Lubrication:
Automatic centralized lubrication system with programmable intervals and low-level warnings supports preventive maintenance and reduces wear on critical sliding surfaces.
Electrical requirements:
480 V / 3-phase / 60 Hz service with appropriate grounding; alternative voltages available by configuration. Full electrical data is provided for panel and load calculations.
Compressed air:
Clean, dry compressed air supply for auxiliary functions and safety systems, compatible with standard US shop air specifications.
Safety, guarding & environmental management
Operator safety:
Dual-hand anti-tie-down controls, safety light curtains, mechanical guards, and emergency stop circuits are integrated to support safe operation in accordance with press brake safety concepts (such as ANSI B11.3).
Noise control:
Hydraulic and structural design help maintain noise levels within typical industrial requirements, supported by vibration-damping mass and controlled pump operation.
Electrical safety:
UL-recognized components, clear separation of high- and low-voltage circuits, main disconnects and ground fault protection are used to support safe, maintainable installations.
Maintenance safety:
Mechanical ram blocks, lockout/tagout provisions and detailed safety procedures help ensure technicians can work on the machine safely during inspections and repairs.
Installation, foundations & facility requirements
Foundation requirements:
Reinforced concrete slab or foundation with sufficient mass and anchor capacity to support machine weight and dynamic loads; detailed drawings provided for engineering review.
Floor space planning:
Recommended clearances in front, rear, and sides for material handling, operator movement, and forklift or crane access are supplied to support efficient layout design.
Utility connections:
Standard industrial connections for electrical power and compressed air; guidelines for lighting and ancillary equipment in the operator work envelope are included.
Rigging & placement:
The machine includes clearly marked lifting points and rigging guidelines for safe unloading, movement and final placement during installation.
Subsystems & accessories
Tooling interface:
Standard American-style clamping (with optional European-style compatibility) supports common punch and die sets, allowing many shops to reuse existing tooling.
Hydraulic filtration:
High-efficiency filters with visual or electronic condition indicators and recommended service intervals help extend hydraulic component life.
Electrical cabinet:
Industrial-rated enclosure with thermal management, good access for service, and clearly labeled wiring and components to speed troubleshooting.
Standard configuration – what you get
- DELEM DA-66T CNC with 15" color touchscreen display.
- 6-axis CNC (Y1, Y2, X, R, Z1, Z2) with servo-driven backgauge.
- CNC-controlled hydraulic crowning system.
- Linear scale feedback on both sides of the frame.
- Bosch-Rexroth hydraulic components and proportional valves.
- Automatic centralized lubrication system.
- Safety light curtains, dual-hand controls, mechanical guards and emergency stop circuits.
- Hydraulic oil cooling and filtration system with initial hydraulic fill.
- Standard American-style tool clamping system.
- Basic punch and die set for initial production.
- Electrical cabinet with main disconnect and labeled circuits.
- Leveling pads and anchor hardware for installation.
- RS-232 and Ethernet communication interfaces.
- Operator, maintenance and programming documentation (digital + print).
- Initial training documentation and parameter sets.
- One-year standard warranty coverage (extended options available).
Capabilities & typical applications
Within its 110 ton forming envelope, the HBF 110/2500 can process a wide range of material types and thicknesses. Exact thickness vs. length limits are confirmed during application review, but typical workloads include medium to heavier gauge mild steel, stainless and aluminum parts in 2500 mm and shorter lengths.
Common applications and industries include:
- Structural brackets, gussets, stiffeners, and base plates for machinery and industrial equipment.
- Frames, cabinets, and enclosures for electrical, HVAC, and power distribution systems.
- Machine guards, panels, and welded subassemblies for OEM and contract manufacturing.
- Medium-format components for construction equipment, material handling, and transport industries.
- Custom fabricated components where tight angles and repeatable flange dimensions are critical.
The machine is equally at home running prototype parts, short batches, and medium-volume repeat orders. High-mix shops benefit from the combination of quick changeovers, programmed job recall, and staged tooling, allowing multiple part families to run on the same brake with minimal downtime.
Implementation, integration, ROI & support
Implementation starts with pre-install planning: foundation review, power checks, and layout planning to align the brake with upstream cutting and downstream welding or assembly operations. With proper site preparation and rigging, many US shops can move from delivery to production in a matter of days.
Operator and programmer training covers DELEM control use, part programming, material handling, basic maintenance and safety procedures. Training can be conducted on-site or at regional facilities, and is supported by digital and printed documentation.
Return-on-investment calculations typically show payback periods driven by reduced setup time, fewer scrap parts, improved angle consistency, and the ability to bring more complex work in-house. The machine’s automation-ready design provides a path to further productivity gains as volumes grow.
Ongoing support includes phone and online technical assistance, field service from regional technicians, and access to stocked spare parts. Preventive maintenance programs with scheduled inspections help maintain uptime and avoid unplanned interruptions.
Next step: send us a sample of your parts (DXF/STEP/PDF) or project requirements, and we’ll confirm tonnage, feasibility, expected cycle times, and a recommended configuration for your operation.
Extended technical FAQ
What facility requirements should we plan for?
The HBF 110/2500 requires a suitable concrete slab or foundation, 480 V / 3-phase / 60 Hz electrical service, clean compressed air, and overhead/side clearance for handling plates and assemblies. Detailed drawings and utility requirements are supplied with the order.
How difficult is the DELEM DA-66T to learn?
The DA-66T is designed for production shops, with graphical programming and simulation tools that reduce the learning curve. Operators with basic CNC or press brake experience typically become productive within a few days of structured training.
How does the 6-axis system improve accuracy and throughput?
Full Y1/Y2, X, R, Z1 and Z2 control allows precise gauging for multi-bend parts, staged tooling, and asymmetric profiles. This reduces manual handling and gauge adjustments and improves angle consistency across part families.
What maintenance routines are recommended for optimal performance?
Daily: visual checks and cleaning. Weekly: lubrication and basic inspection. Monthly: hydraulic, backgauge and safety system checks. Annually: in-depth inspection and service by qualified technicians. Detailed schedules and procedures are provided with the machine.
Can this machine be integrated with robotic automation?
Yes. The HBF 110/2500 includes standard interfaces for robot integration and has a control architecture that supports handshaking, I/O, and safety logic used in automated cells. Integration details are finalized during the project engineering phase.
What setup times can we expect between jobs?
With staged tooling, job recall and a consistent tooling strategy, typical changeovers are measured in minutes rather than hours. Exact times depend on part complexity and the degree of standardization in your tooling.
What standards and safety concepts does the machine follow?
The brake is designed around established press brake safety concepts (such as ANSI B11.3) and uses CE-marked safety components. Documentation can be provided to support internal safety and compliance reviews.
What uptime can we expect in a production environment?
With routine maintenance and operation within its rated envelope, the HBF 110/2500 is engineered for 95%+ uptime in multi-shift operations, supported by regional service and spare parts availability.
How does the machine handle different materials and thicknesses?
The DA-66T control can store material libraries and custom bend data for different alloys and thicknesses. Once dialed in, the hydraulic and crowning systems provide consistent bending from job to job, even when switching between materials.
