Umprotech 96in 14ga Box & Pan Brake – Segmented Finger Brake
A robust 96 inch box and pan (finger) brake engineered for US sheet metal shops, HVAC fabricators, and prototyping teams. Designed for high-mix forming of ductwork, panels, and custom boxes in 14 gauge mild steel.
Capacity: 96 in · Material: 14 gauge mild steel · Segmented fingers: 1–4 in set
Key advantages for US buyers
- 96 inch working length handles full-size panels, duct sections, and large enclosures.
- 14 gauge mild steel capacity supports a wide range of shop and field parts; suitable for most HVAC, electrical, and fabrication jobs.
- Segmented finger set (1–4 inch mix) enables forming of complex boxes, pans, and channels with variable flange depths.
- Adjustable apron and angle stop improve repeatability for production runs and prototypes.
- Counterbalance springs reduce operator fatigue and support smooth operation even on longer bends.
- Back-gauge ready for improved accuracy and efficiency in repetitive forming tasks.
Key technical specifications
Working length: 96 in
Accommodates standard 8 ft sheets for ductwork, cabinetry, and large panels.
Material capacity: 14 gauge mild steel
Designed for reliable forming of 14ga mild steel; reduced capacity for stainless steel.
Segmented fingers: 1–4 in mix
Allows flexible setups for box, pan, and custom profile work.
Apron & angle stop: Adjustable
Supports precise repeat bends and consistent angles across batches.
Counterbalance: Springs included
Assists with manual operation, especially on long or heavy bends.
Back-gauge: Ready
Prepared for integration of a back-gauge system to enhance accuracy and productivity.
Capabilities & typical applications
This segmented finger brake is a core tool for shops focused on forming sheet metal parts, supporting both custom and production work. It integrates well alongside shears, CNC folders, and plasma or laser cutting cells.
- Forming boxes, pans, channels, and custom enclosures
- HVAC ductwork, electrical cabinets, and control panels
- Prototyping and short-run production for job shops
- General fabrication for machinery, construction, and OEM parts
- High-mix/low-volume production where flexibility and quick setups are critical
Implementation & support for US shops
We support US fabricators with practical advice on installation, part fit-up, and workflow integration. Our team can review your typical parts and material thicknesses to confirm this brake is the right fit for your jobs.
We help with initial setups, finger arrangements, and best practices for forming accuracy and repeatability. Training and commissioning are available to get your team up to speed quickly.
- Pre-installation guidance on floor space, access, and utilities
- Assistance with finger setup and bend sequences
- Advice on integrating with shears, folders, and cutting equipment
Next step: Send us sample part drawings or specs, and we’ll confirm fit and configuration for your application.
