Umprotech 72in 16ga Box & Pan Brake – Segmented Finger Brake
Heavy-duty box and pan brake with segmented fingers for precise sheet metal forming. Built for US job shops, HVAC, and fabrication teams handling prototypes, ductwork, and custom enclosures. Designed for flexibility, accuracy, and ease of setup in high-mix environments.
Working length: 72 inch · Capacity: 16 gauge mild steel · Segmented fingers: 1–4 in mix
Key advantages for US buyers
- 72 inch working length handles common ductwork, panels, and medium-sized enclosures.
- 16 gauge mild steel capacity (less for stainless) covers most HVAC, electrical, and prototyping needs.
- Segmented finger set (1–4 in mix) enables forming of complex boxes, pans, and channels with return flanges.
- Adjustable apron and angle stop for repeatable bends and fast setup changes.
- Counterbalance springs reduce operator fatigue during longer runs.
- Back-gauge ready for improved accuracy and faster part positioning.
Key technical specifications
Working length: 72 inch
Accommodates full 6 ft sheets for panels, duct sections, and cabinet work.
Capacity: 16 gauge mild steel
Handles typical HVAC, electrical, and fabrication materials. (Capacity is less for stainless steel.)
Segmented fingers: 1–4 inch mix
Allows for custom setups to bend boxes, pans, and channels with tight return flanges.
Features: Adjustable apron, angle stop, counterbalance springs, back-gauge ready
Supports accurate, repeatable bends and efficient operation.
Capabilities & typical applications
This box & pan brake is a flexible forming solution for shops running a variety of small to medium sheet metal parts. It fits well as a standalone forming cell or as part of a workflow with shears, CNC folders, or laser cutters.
- HVAC ductwork (transitions, elbows, plenums)
- Electrical enclosures, panels, and cabinets
- Prototyping and short-run custom parts
- Brackets, trays, and structural channels
- General fabrication for job shops and contract manufacturers
Implementation & support for US shops
We work closely with US job shops, HVAC contractors, and OEMs to ensure a smooth integration. Our team can review your typical part mix, material types, and shop layout to confirm fit and optimize your setup.
- Pre-installation review of floor space, power, and workflow
- Guidance on finger setup, apron adjustment, and angle stop usage
- Support for basic bend sequences and tooling strategies
- Training and handover to get your team productive quickly
Next step: Send us a few sample part drawings or photos, and we’ll confirm fit, cycle time, and configuration for your application.
