Umprotech 72in 12ga Box & Pan Brake – Segmented Finger Brake
A robust 72 inch box & pan brake with segmented fingers, built for US job shops and OEMs handling 12 gauge mild steel. Designed for versatility in ductwork, cabinetry, and prototype fabrication where repeatability and flexibility are critical.
Working length: 72 in · Capacity: 12 ga mild steel · Clamping: Manual, Foot, or Hydraulic Assist
Key advantages for US buyers
- 72 inch working length accommodates panels, duct sections, and cabinetry up to 6 feet wide.
- 12 gauge mild steel capacity (less for stainless) supports a wide range of sheet metal jobs.
- Segmented finger set (1–4 inch mix) enables forming of complex boxes, pans, and custom profiles.
- Adjustable apron and angle stop for consistent, repeatable bends across production runs.
- Available in manual clamp, foot clamp, or hydraulic assist to fit your workflow and budget.
- Back-gauge ready for integration with shop measuring systems or future upgrades.
Key technical specifications
Working length: 72 in
Handles sheet sizes up to 6 feet, ideal for ductwork, panels, and enclosures.
Material capacity: 12 gauge mild steel
Supports most common HVAC, fabrication, and job shop requirements. (Capacity is less for stainless steel.)
Segmented fingers: 1–4 in mix
Allows for forming closed boxes, pans, and custom shapes with minimal tool changes.
Clamping options: Manual, Foot, Hydraulic Assist
Select the clamping method that matches your throughput and operator needs.
Features: Adjustable apron, angle stop, counterbalance springs, back-gauge ready
Engineered for repeatability, safe operation, and future expandability.
Capabilities & typical applications
This box & pan brake is a core tool for forming operations in HVAC, general fabrication, and prototype work. It’s equally at home in standalone setups or as part of a forming cell feeding welders or assembly lines.
- Forming ductwork, electrical enclosures, panels, and custom boxes
- Fabricating cabinetry, trays, brackets, and structural components
- Prototyping and short-run production for job shops and OEMs
- Supporting high-mix, low-volume workflows with quick finger changes
- Integrates with shears, saws, and welding stations for a complete sheet metal line
Implementation & support for US shops
We work closely with US job shops, OEMs, and fabricators to ensure smooth installation and fast ramp-up. Our team can review your parts, materials, and floor space to confirm fit before purchase. We assist with setup, finger changes, and bending sequences so your operators are productive from day one.
- Pre-install planning: power, floor, material flow, safety, and access
- Application review: confirm your material thicknesses and part sizes
- Training: setup, finger configuration, and best practices for repeatability
Next step: Send us a few sample part drawings or specs and we’ll confirm fit, cycle time, and the right configuration for your workflow.
