Umprotech Box & Pan Brake – 60 in · 16 ga · Segmented Fingers
Precision box & pan brake for US metal fabrication shops. 60 inch working length and 16 gauge mild steel capacity, with segmented fingers for forming complex shapes. Designed for HVAC, job shops, and prototyping where flexibility and repeatability matter.
Working length: 60 in · Capacity: 16 ga mild steel · Segmented fingers: 1–4 in mix
Key advantages for US buyers
- 60 inch working length covers typical ductwork, panels, and medium-sized enclosures.
- 16 gauge mild steel capacity (less for stainless) supports a wide range of shop jobs and prototypes.
- Segmented finger set (1–4 in mix) enables forming of boxes, pans, and custom profiles with return flanges.
- Adjustable apron and angle stop ensure consistent, repeatable bends for production or high-mix work.
- Counterbalance springs reduce operator fatigue during long runs.
- Back-gauge ready design streamlines part positioning and improves accuracy.
Key technical specifications
Working length: 60 in
Handles panels, duct sections, and medium-sized parts up to 5 feet wide.
Material capacity: 16 gauge mild steel
Suitable for most HVAC, fabrication, and prototyping jobs. (Capacity is less for stainless steel.)
Segmented fingers: 1–4 in mix
Configure the tooling to form boxes, pans, and parts with intricate bends or return flanges.
Adjustable apron & angle stop
Dial in precise bend angles and repeatable results across batches.
Counterbalance springs
Assist the operator and reduce effort during repetitive bending operations.
Back-gauge ready
Easily add a back-gauge for improved part positioning and repeatability.
Capabilities & typical applications
This box & pan brake is a core tool for shops handling ductwork, electrical enclosures, custom panels, and prototype parts. Its segmented fingers and 60 inch length make it ideal for both production and job shop environments.
- Forming boxes, pans, and trays with return flanges
- HVAC ductwork and fittings up to 16 gauge mild steel
- Electrical cabinets, covers, and medium-sized panels
- Prototype and short-run parts for contract manufacturing
- General fabrication for job shops and OEMs
Implementation & support for US shops
We help US fabricators and OEMs select, install, and integrate box & pan brakes for maximum productivity. Our team can review your part drawings, material specs, and workflow to confirm fit before purchase.
- Pre-install checks for floor space, access, and power requirements
- Guidance on finger setup, bend sequences, and forming strategies
- Operator training and commissioning for a fast, confident start-up
Next step: Send us sample part drawings or specs, and we’ll confirm the right configuration and support your team from install to first production run.
