Umprotech Box & Pan Brake – 48 in, 20 ga, Segmented Fingers
A robust segmented finger brake for precise forming of boxes, pans, and ductwork. Designed for US sheet metal shops needing flexibility and repeatability in 48 inch, 20 gauge work.
Working length: 48 in · Capacity: 20 ga mild steel · Finger set: 1–4 in mix
Key advantages for US buyers
- 48 inch working length handles common panel and enclosure sizes for HVAC, electrical, and fabrication jobs.
- 20 gauge mild steel capacity covers most light-gauge forming needs; suitable for prototyping and short-run production.
- Segmented finger set (1–4 in mix) enables fast setups for complex box and pan profiles.
- Adjustable apron and angle stop for repeatable bends and precise angles.
- Available with manual, foot, or hydraulic assist clamping to match shop workflow and operator preference.
- Counterbalance springs reduce operator fatigue during high-mix jobs.
- Back-gauge ready for improved part consistency and throughput.
Key technical specifications
Working length: 48 in
Supports forming of panels, boxes, and ductwork up to 4 feet wide.
Maximum capacity: 20 gauge mild steel
Handles standard light-gauge steel; capacity will be lower for stainless steel.
Segmented fingers: 1–4 in mix
Allows quick setup for different box widths and depths.
Clamping options: Manual, Foot, Hydraulic Assist
Choose the clamping style that best fits your production volume and ergonomics.
Features: Adjustable apron, angle stop, counterbalance springs, back-gauge ready
Enhances repeatability, operator comfort, and productivity.
Capabilities & typical applications
This box and pan brake is a workhorse for light-gauge forming in job shops, HVAC contractors, and custom fabrication cells. Its segmented design makes it ideal for high-mix, low-volume runs and prototyping.
- Forming boxes, pans, trays, and enclosures up to 48 in wide
- Ductwork, electrical cabinets, and small chassis
- Prototype and repair work for general fabrication
- Suitable for mild steel up to 20 gauge; also works with aluminum and lighter stainless (with reduced capacity)
- Integration in bending/forming cells alongside shears, saws, or turret punches
Implementation & support for US shops
We work closely with US job shops, HVAC contractors, and OEMs to ensure the right fit before purchase. Our team can review your parts, material types, and thicknesses to confirm suitability and recommend the best clamping configuration.
We assist with setup, finger arrangements, and basic bend sequences so your team is productive from day one. If you need to integrate with back-gauges or other shop equipment, we can advise on workflow and layout.
- Pre-installation consultation for floor space, power, and material flow
- Guidance on finger setup and bend strategies for your parts
- Training and handover support available
Next step: Send us a few sample part drawings or photos, and we’ll confirm fit and recommend the right configuration for your shop.
