    Umprotech Box & Pan Brake – 48 in, 16 Gauge, Segmented Fingers

    A robust segmented finger brake for US sheet metal shops, the Umprotech 48 in 16ga box & pan brake delivers precise forming for ductwork, boxes, and prototyping. Designed for versatility and repeatability, it’s ideal for fabrication cells, HVAC, and job shops handling a range of part sizes and profiles.

    Working length: 48 in · Capacity: 16 gauge mild steel · Segmented fingers: 1–4 in mix

    Key advantages for US buyers

    • 48 in working length accommodates panels, duct sections, and enclosures up to 4 feet wide.
    • 16 gauge mild steel capacity covers most HVAC, electrical, and general fabrication needs.
    • Segmented finger set (1–4 in mix) enables forming of complex boxes, pans, and custom profiles.
    • Adjustable apron and angle stop support repeatable bends and consistent results.
    • Counterbalance springs reduce operator fatigue during repetitive forming tasks.
    • Back-gauge ready design streamlines part positioning for higher throughput and accuracy.

    Key technical specifications

    Working length: 48 in

    Allows fabrication of panels, ductwork, and boxes up to 4 feet wide.

    Capacity: 16 gauge mild steel

    Handles typical sheet metal thicknesses for HVAC, electrical, and light fabrication. (Note: lower capacity for stainless steel.)

    Segmented fingers: 1–4 in mix

    Configure for custom bends, return flanges, and tight box/pan geometries.

    Adjustable apron & angle stop

    Supports controlled, repeatable bends for production or prototyping.

    Counterbalance springs

    Assist with apron movement, reducing operator effort on larger jobs.

    Back-gauge ready

    Facilitates precise part positioning and repeat work.

    Capabilities & typical applications

    This segmented finger brake is a core tool for forming boxes, pans, and custom profiles in a standalone cell or as part of a full fabrication workflow. Its 48 in length and 16 gauge capacity make it suitable for a wide range of job shop and OEM needs.

    • Fabrication of boxes, pans, trays, and cabinets
    • Ductwork for HVAC contractors and sheet metal shops
    • Electrical enclosures, covers, and chassis
    • Prototyping and short-run production for custom parts
    • General job shop forming for brackets, channels, and frames

    Configurations & options

    Configure your Umprotech box & pan brake to match your workflow and operator preferences. Multiple clamping styles and accessory options are available to suit different production environments.

    • Manual Clamp: Simple, reliable clamping for low to moderate volume work.
    • Foot Clamp: Hands-free operation for improved speed and ergonomics.
    • Hydraulic Assist: Enhanced clamping force and reduced operator effort for higher throughput or heavier material handling.
    • Includes segmented finger set (1–4 in mix) as standard.
    • Back-gauge ready for integration with shop positioning systems.

    Implementation & support for US shops

    We work closely with US job shops, OEMs, and HVAC contractors to ensure your brake is correctly specified and seamlessly integrated. Our team reviews your parts, thicknesses, and shop layout to confirm fit and productivity before purchase.

    We can assist with setup, finger configuration, and best practices for forming complex geometries—so your team is productive from day one.

    • Pre-installation checks for floor space, access, and workflow
    • Guidance on finger setup for specific part runs
    • Operator training on repeatable bends and safe operation

    Next step: Send us a sample drawing or part spec, and we’ll confirm fit and configuration for your jobs.
